The Mobile Terminal M3 was designed for industrial use and is of outstanding durability. It proved unmatched ruggedness to perform in extreme environments through a large variety of durability tests.

With its combination of a powerful Intel X-scale PXA270 624 / 806 MHz processor and the user friendly Windows Mobile 6.5 operating system, the M3 Orange allows running many different applications, not least because of the up to 256 MB SDRAM and 1024 MB Flash memory.

The new Mobile Terminal M3 Orange is equipped with an advanced UHF Long-Range RFID module. This powerful module offers a reading range of up to 1 m in combination with a long battery life time. The M3 Orange UHF Long-Range is available with modules for all common global frequencies (865-960 MHz). Especially the working flow of applications like maintenance and asset tracking can be improved with iDTRONIC’s Mobile Terminal M3 Orange.

This exclusive and competitive combination is only available through iDTRONIC and our distribution partners. To go without saying, the M3 Orange is still available with a HF RFID module as well.

Additionally to this new hardware, iDTRONIC offers a wide variety of accessories and service contracts which can be individually modified to the customers demand.

For further information and updated news about all iDTRONIC products please go to http://idtronic-rfid.com or write us an e-mail: info@idtronic.de

In this case, the modern RFID technology allows a rapid and steady registration of passing vehicles over a distance of several meters. The new and very thin Windshield Tag UHF is simply stuck on the pane, whether inside or outside — the functionality stays the same. The tag is weather-proof, UV resistant and equipped with a theft protection, ensuring the designated usage (Maximum safety: chip destroyed when removing tag).

In addition, the functionality of the new tag can be expanded. In combination with the RFID technology, barcode and 4c logo print as well as the integration of further safety features is smoothly realizable: The Windshield Tag UHF can be designed so that it perfectly fits to your application.

Applications

• Access control to carparks
• Automatic toll systems
• Production and logistics

The dimensions of the new iDTRONIC Windshield Tag UHF are 105 × 35 × 0.2 mm and it consists of 2 layers polyester. It stands temperatures of up to +150 °C.

For further information and updated news about all iDTRONIC products please go to http://idtronic-rfid.com or write us an e-mail: info@idtronic.de

The BLUEBOX Professional RFID product highlights are

• Available for UHF, HF, and LF RFID integration
• Solutions for Short-, Mid-, and Long-Range applications
• Controllers for running 1, 2, and 4 antennas
• Multiple interface options
• Ruggedized product designs and housings
• Unique SDK for all BLUEBOX products
• Made in Germany

The latest generation of BLUEBOX Professional RFID products features additional enhancements, which are

• Faster processing thanks to improved ARM processor
• Internal backup memory
• M12 connections for trouble-free and secure mounting
• Profinet and Ethernet/IP interfaces available
• Extended range of application specific antennas
• Improved SDK with demo applications

Also available as a Start-Up-Kit “BLUEBOX Basic” as well as a desktop version “BLUEBOX desktop”

In-Metal Tags UHF and On-Metal Tags UHF

The new iDTRONIC In-Metal tags UHF and On-Metal tags UHF come in rugged IP68 housings. They have been designed for very harsh environments and can be used in a large number of applications such as Asset Tracking, Industrial Automation and Supply Chain. With up to four meter reading distance and a very large application temperature range, the tags can deliver significant value in your application.

Key Features and Benefits of The New On-Metal Tags UHF

• Performs On-metal with read range of up to 6 meters
• IP68 rated to handle high application temperatures up to +250 °C
• Large user memory (up to 32 kBytes)
• Available dimensions:
      » OM2:   18 × 11 × 5 mm
      » OM3:   32 × 13 × 5 mm
      » OM4: 100 × 26 × 9 mm

==> Click here to see datasheet

Key Features and Benefits of The New In-Metal Tags UHF

• Performs In-metal with read range of up to 4 meters
• Ceramic Material to handle embeddable in In-Metal applications
• High application temperatures up to +150 °C
• Large user memory (up to 32 kBytes)
• Available dimensions:
      » IM2:   12 × 7 × 3 mm
      » IM3:   25 × 9 × 3 mm
      » IM4:   30 × 30 × 3 mm

==> Click here to see datasheet

High-Temperature tag UHF

The iDTRONIC High-Temperature tag UHF tag has been specifically designed to perform under extreme heat and repeated exposure to caustic fluids for applications such as autoclaves, hot water wash cycles and post-paint processes. The iDTRONIC High-Temperature tag UHF is constructed with IP68 rating for high reliability and durability in all types of environments. The tag survives applications with temperatures of up to 250 °C and other harsh elements such as high impact and caustic chemicals. The design of the iDTRONIC High-Temperature tag UHF has been done as well for the use on metal objects / structures.

Key features and benefits of the new High-Temperature Transponder

• On-metal tags with read range of up to 6 meters
• IP68 rated rated to handle high application temperatures
• +250 °C application temperature for up to 4 hours
• Large user memory (up to 32 kBytes)
• Small form factor with 51 × 37 × 8 mm

==> Click here to see datasheet

Tool Tags UHF

The iDTRONIC UHF tool tags UHF have been designed especially for healthcare and tool tracking applications. In healthcare, the compliance with FDA requirements for Unique Device Identification enables the costumer to track automatically all surgical tools and reduce the risks of foreign object debris (FOD) and infection control. The tool tags can be mounted on metal or embedded in metal and will withstand repeated autoclave cycles.

For tool tracking, the tags can mounted on metal or embedded in metal and will withstand repeated chemical washing cycles. The IP68 housing allows a usage in harsh environments similar to construction sides. It enables the costumer to track automatically all tools and reduce risks of product recalls or missing equipment.

With up to 1.5 meters reading distance and their temperature ranges, the transponders can deliver significant value to many applications in health care and industrial environments.

Key features and benefits of the new iDTRONIC Tool Tags UHF

• World’s smallest passive UHF EPC Class 1 Gen 2 tags
• Performs On-metal with read range of up to 1.5 meter & In-Metal with up to 1 meter
• IP68 rated to handle high application temperatures up to +150 °C
• Compliant with FDA requirements
• Withstand repeated autoclave and chemical washing cycles
• Available dimensions:
      » TT2:   12.3 × 3.2 × 2.3 mm
      » TT3:   Ø 6 × 2.5 mm

==> Click here to see datasheet

Thanks to the integrated pistol grip with 4400 mAh battery plus a standard 3000 mAh battery, the UHF Gun guarantees easy handling and a very high autonomy.

The standard communication is provided with the integrated USB. With Interface options like Bluetooth, WiFi 802.11b/g, GSM and GPRS the communication capability of the RFID Terminal UHF Gun can be extended further.

As well available are 1D Laser scanner, 2D Barcode imager and 1.3 MPixel Camera.

This durable dust and water resistant device supports what you need to work and enables you to help increasing productivity and efficiency. Also convenient docking stations make charging and synchronizing easier than ever in both office and vehicle.

Applications

• Logistics
• Distribution
• Asset Tracking
• Identification

Features

• Supports ISO18000-6 C (incl. C1G2)
• Up to 2 m reading distance
• Small form factor => Lightweight / High mobility
• Windows CE 5.0
• USB
• Bluetooth + WiFi 802.11 b/g (Option)
• GSM / GPRS / EDGE (Option)
• 1.3 MPixel Camera (Option)
• Touchscreen LCD
• 3000 + 4400 mAh battery => Very high autonomy
• CE approved
• IP65

Options

• Optional communications: Bluetooth
• 1D Laser Scanner
• 2D Barcode Imager
• 1.3 MPixel fixed focus camera with flash
• GPS Receiver
• USB Cradle
• Vehicle Cradle
• WiFi 802.11b/g
• CDMA EVDO or 2000 1X,
• GSM/GPRS/EDGE, WCDMA

Order Code: R-HH-GUN-UHF

The Mobile UHF Bluetooth Reader I-POLL can be configured for Single Read or Inventory Mode. The collected data is sent in real time to the PC or PDA. With its excellent anti-collision capabilities, which allow it to read dozens of tags simultaneously, it is particularly well-suited for warehouse and library applications. Its advanced antenna design allows long read distances up to 2 m. The user interface consists of 2 scan buttons, one buzzer and two coloured LEDs.

Applications

• Library
• Warehouse
• Department Store
• Asset Tracking

Built in Barcode scanner, camera, HSPA, WLAN, GPS and 3M AF Camera, HF/UHF RFID reader in slim and rugged PDA. Rugged and secured device that certify IP 54 and 1.5m drop test guaranty best performance in tough working environment.

Flexible communication system

• Flexible communication system with HSPA, WLAN and Bluetooth.
• Easy data send/receive and synchronize with other device.
• Easy read and scan barcode with powerful laser barcode scanner.

• Built in Samsung ARM 11 800 MHz for high speed data processing.
• 60 % slimer, compacter and lighter device than other hand-held terminal.
• Apply Windows CE 5.0 for security and OS scalability.

Support variety working environment

• Flexible options for variety working environment
• 1D/2D barcode scanner, GPS, WiFi, Bluetooth, GSM, Camera, HF RFID reader
• High performance, easy user interface barcode scanner
• Specialized PDA for Logistics, Parcel delivery and tracking business.

User Friendly designed terminal

• Ergonomical design as light weight and steamline body for long time work.
• Sepcial design for barcode reading angle for easy scanning and reading.
• User friendly accessories.

• Built-in high performance CPU Marvell PXA320 806 MHz
• which is 20 % faster than PXA270 in processing speed
• Built-in mass storage (ROM 128 MB, RAM 256 MB)
• Extend battery life using by 1,800 mAh battery and low power architecture PAX320 CPU

Customer Orientation POS Terminal

• All-in-One Structure (GPS, Wireless lan, Bluetooth, CDMA, Barcode Scanner, Digital Camera, Printer, MSR, IC CARD, RFID Reader and so on)
• Fully support next generation payment application ( IC Card, Smart Card)
• Prevention financial incident by fingerprint verification technology
• Reduce the waiting time with faster print speed.

User Orientation United Terminal

• User orientation united payment terminal with convenience & scalability
• Support various united payment system
• Convenience one touch switchgear system for replacing printer paper
• Designed to consider working environment

iDTRONIC offers innovative RFID hardware solutions for a broad range of applications within the area of industrial and process automation. iDTRONIC RFID Controllers, Readers, Antennas as well as all connectivity products such as passive junctions, connectors and fieldbus cables are all modular and available for all kinds of requirements.

iDTRONIC Special RFID tags have been designed also to be used in any industrial environment. For example RFID tags that can withstand not only high temperature, but also can withstand for example a constant heating and cooling cycle without loosing the data in the RFID tag.

The iDTRONIC Group offers a range of modular RFID products for the Industrial Automation.

iDTRONIC Professional RFID

• Bluebox Professional RFID
• Mobile RFID Readers
• OEM RFID Readers
• Professional RFID Tags

Textiles can be easily identified by the use of RFID technology,with amazing advantages for industrial laundries. Benefits include faster garment identification, automatic sorting, error-free processing, reduced manual labor and long lasting solutions. The amortization factor of RFID systems in industrial laundry applications is very high.

It all begins with an RFID tag attached to a garment or linen.  The industry has created a series of ISO standards-based, high-frequency 13.56 MHz tags that are encapsulated in plastic to withstand the harsh temperatures and detergents found in commercial laundries. Tags are programmed with a unique ID number that can be read and processed. RFID tagged garments can be read while stored in bags or racked on hanger bundles.

iDTRONIC Group offers fast and accurate RFID hardware products for the textile identification market.

iDTRONIC Professional RFID

• Bluebox Professional RFID
• Mobile RFID Readers
• OEM RFID Readers
• Professional RFID Tags

RFID offers benefits from the manufacturing facility all the way through to the point of sale. Immediate benefits of utilizing RFID tags for retail include inventory accuracy, decrease in inventory count time, reduced man hours required for restocking, improved customer service with increased man hours available for customer interaction, increased in-stock position and shelf level accuracy and more efficient back room replenishment.

RFID allows retailers to complement existing systems while gathering more information throughout the whole application. Systems with the power to update the information that moves with an individual product provide complete visibility.

RFID also can act like a security guard at a gateway. As goods are moved from dock to truck to store, RFID can conduct automatic inventories and compare the goods with the manifest. Goods flow becomes more complete, stock outs are reduced, overages are curtailed and accounting discrepancies are removed. RFID tagged products also ensure perfect brand authentication.

The iDTRONIC Group offers a range of RFID products designed for retail application.

iDTRONIC Professional RFID

• Bluebox Professional RFID
• Mobile RFID Readers
• OEM RFID Readers
• Professional RFID Tags

RFID technology creates transparency to ensure continuous optimization of the manufacturing processes, compliance with legal regulations and standards as well as achieving maximum quality for the end consumer.

Almost any enterprise can use RFID technology to automate Supply Chain Management and Transportation Management functions such as proof of delivery, automated replenishment, and inventory tracking. RFID data can be easily incorporated into back-end enterprise planning (ERP) systems and exchanged between trading partners as a component of their EDI messages.

The RFID-enabled Supply Chain provide detailed information about the status and position of the goods, thus reducing costs and speeding up consumer protection.

The iDTRONIC Group offers interesting RFID hardware products designed for Supply Chain applications.

iDTRONIC Professional RFID

• Bluebox Professional RFID
• Mobile RFID Readers
• OEM RFID Readers
• Professional RFID Tags

By automating the collection of all waste, RFID can assure that individual bins have been collected, providing verification of service. In addition this information can be used to optimize truck usage and routes. Processes can be streamlined and more accurate.

RFID technology helps a lot to increase efficiency of the waste management operations. To realize this application, a properly designed rugged RFID tag is attached to the waste bins. It contains all user/owner information.

An RFID reader/antenna embedded into the truck captures the tag IDs of each waste bin. The data collected from the RFID tags can be linked with a time stamp, type of container, weight of the container, and customer information. The data can be either sent to a host computer using wireless protocols or the data can also be stored in the truck’s onboard computer and later transferred to a central waste management system for data processing.

The iDTRONIC Group offers specially designed RFID products for the Waste Management application.

iDTRONIC Professional RFID

• Bluebox Professional RFID
• Mobile RFID Readers
• OEM RFID Readers
• Professional RFID Tags

Data security is generally very high using RFID technology. It also reduces the possibility of duplicating credentials. Secure or proprietary communication protocols can also be used to further enhance security.

A RFID based Access Control reader does not usually make an access decision but send a card number to an Access Control panel that verifies the number against an access list. Generally only entry is controlled and exit is uncontrolled. In cases where exit is also controlled a second reader is used on the opposite side of the door. The typical RFID tag is a RFID based contactless smartcard, key fob, wristband or smartphone sticker.

RFID based Access Control Systems are typically used for Enterprise Access, Car Park Access, Access to Gyms or Swimming Areas, Event Access, Library Access or Access to Hotel Rooms.

The iDTRONIC Group offers an extensive range of Access Control products to cover these applications.

iDTRONIC Smart RFID

• Eazy Axxess System

iDTRONIC Smart Tags

• RFID Smartcards
• RFID Keyfobs
• RFID Wristbands
• RFID Wristbands, sealed
• RFID Tickets

iDTRONIC Professional RFID

• BLUEBOX UHF Mid Range Controller (for Carpark Access)

The user can instantly determine the general location of tagged assets anywhere within a facility with the help of RFID technology. Control point detection zones at strategic locations throughout the facility allow the user to define and monitor logical zones.

Using RFID-based Asset Management systems make sure that basic information and continuous traceability is made available at each moment. RFID technology creates transparency to ensure continuous optimization in compliance with legal regulations and standards. Asset tracking applications will see a strong growth curve in the coming years.

The iDTRONIC Group offers a range of RFID products for mobile and stationary Asset Tracking applications.

iDTRONIC Professional RFID

• Bluebox Professional RFID
• Mobile RFID Readers
• OEM RFID Readers
• Professional RFID Tags

The transponders, which comes in both a rugged, IP68-cased On Metal version and an embeddable In-Metal version, are perfectly suited for the harshest of environments and can be used in a diverse number of applications such as asset tracking, industrial automation and supply chain management.

With up to four meter reading distance and their temperature ranges, the transponders can deliver significant value in the following areas: storing key life-cycle history information of an asset, accessing information in remote locations, and simplifying deployment without the need for complex IT integration.

Key features and benefits of the new On-Metal Transponders

• On-metal tags with read range of up to 6 meters
• IP68 rated to handle high application temperatures up to +250 °C
• Large user memory (up to 32 kBytes)
• Available dimensions:
      » OM2:   18 × 11 × 5 mm
      » OM3:   32 × 13 × 5 mm
      » OM4: 100 × 26 × 9 mm

Key features and benefits of the new In-Metal Transponders

• In-Metal tags with read range of up to 4 meters
• Ceramic Material to handle embeddable in In-Metal applications
• High application temperatures up to +150 °C
• Large user memory (up to 32 kBytes)
• Available dimensions:
      » IM2: 12 × 7 × 3 mm
      » IM3: 25 × 9 × 3 mm
      » IM4: 30 × 30 × 3 mm

Key features and benefits of the new High-Temperature Transponder

• On-metal tags with read range of up to 6 meters
• IP68 rated rated to handle high application temperatures
• +250 °C application temperature for up to 4 hours
• High user memory (up to 32 kBytes)
• Small form factor with 51 × 37 × 8 mm

Applications

• Industrial Automation
• Asset Tracking
• Access Control
• Waste Management

The device has 1 antenna port for connecting 1 UHF antenna. The IP65 protected device has a reading distance of up to 3 m (depending on type of antenna and tag) with SW adjustable RF power of up to 27 dBm. The reader allows the connection of a single antenna with a impedance of 50 Ohm. The standard antenna is our BLUEBOX UHF Mid Range antenna.

Applications

• Industrial Automation
• Asset Tracking
• Access Control
• Waste Management

Through its circular polarized setting, the user will be able to read out the tags in multiple 3D orientations.

Applications

• Industrial Automation
• Asset Tracking
• Access Control
• Waste Management

The separate antenna allows an easy set up for the most common RFID applications. The 3 available antenna sizes are perfectly designed for built into POS devices, but also can be used for ticketing, payroll systems, time attendance, access control systems and vending machines.

Highlights of the Mini OEM Reader HF

• Supported ISO standards:
      » ISO 14443
      » ISO 15693
      » NFC
• RS232, RS485 or TTL
• MS Windows XP & 7 compliant
• Full SDK with demo software

Applications

• Ticketing
• Payroll Systems
• Access Control
• Time Attendance
• Vending Machines

iDTRONIC’s OEM Readers come with a complete SDK and MS Windows based application Software.

The BLUEBOX Controller UHF LR-4CH is a 860-960 MHz Read/Write device with a 4 channel multiplexer allows the connection of up to 4 external antennas. The reading distance of this IP65 protected device can be up to 10 meters (at 1 W RF power) with SW adjustable RF power of up to 2 W (33 dBm).

Applications

• Industrial Automation
• Asset Tracking
• Access Control
• Waste Management

Through his circular polarized setting, the user will be able to read out the tags in multiple 3D orientations.

Applications

• Industrial Automation
• Asset Tracking
• Access Control
• Waste Management

Through his linear polarized setting, the user will be able to read perfectly tags which are all oriented in the same direction with the least possible interferences.

Applications

• Industrial Automation
• Asset Tracking
• Access Control
• Waste Management

The BLUEBOX Evaluation Gate UHF is specially configured for developing UHF Long-Range applications. It is a complete solution in hardware and software, including software tools with drivers, demo application and full SDK to start the development of your specific application.

Applications

• Industrial Automation
• Asset Tracking
• Access Control
• Waste Management

iDTRONIC’s BLUEBOX UHF Portal consists of the BLUEBOX Controller UHF LR–4 CH plus 4 circular polarized UHF antennas. The standard interface for this device is Ethernet. Other interfaces are available on request.

Applications

• Industrial Automation
• Asset Tracking
• Supply Chain

Applications

• Industrial Automation
• Asset Tracking
• Access Control
• Waste Management

Applications

• Industrial Automation
• Asset Tracking
• Access Control
• Waste Management

Applications

• Industrial Automation
• Asset Tracking
• Access Control
• Waste Management

The BLUEBOOX Panel Antenna HF is the perfect devices for access control, supply chain and library applications. It fits perfectly with iDTRONIC HF Controllers.

Applications

• Access Control
• Production Control
• Library

iDTRONIC`s BLUEBOX cylindrical antennas HF are designed for industrial applications. These antennas fit perfectly with iDTRONIC`s BLUEBOX 13.56 kHz Controllers. The reading distance can be up to 12 cm (depending on tag type).

Applications

• Industrial Automation
• Waste Management

iDTRONIC`s BLUEBOX cylindrical Reader HF is the perfect device for industrial applications. This reader with integrated antenna fits into applications where small dimensions are needed. It is compliant to ISO 15693 + ISO 14443 A. The reading distance can be up to 10 cm (depending on tag type).

Applications

• Industrial Applications
• Production Control

Applications

• Industrial Automation
• Asset Tracking
• Access Control
• Waste Management

iDTRONIC`s BLUEBOX panel antennas Mid-Range HF fit perfectly with iDTRONIC’s BLUEBOX HF Mid-Range Controllers.

The BLUEBOX panel antennas Mid-Range HF are available in 4 different dimensions and guarantee reading distances up to 32 cm.

Applications

• Industrial Applications
• Production Control
• Supply Chain Management

The BLUEBOOX Panel Antennas HF Long-Range are the perfect devices for access control, supply chain and library applications. They fit perfectly with iDTRONIC HF Long Range Controllers.

The iDTRONIC Panel Antennas HF Long-Range are available in 3 different dimensions. The reading distance can be up to 120 cm (depending on antenna and tag type). Thanks to an easy accessible integrated antenna tuning board, the antenna can easily be adjusted to special environments.

An integrated LED indicates the tag reading process. Thanks to a special sealing inside the antenna area, the iDTRONIC HF Panel Antenna Long-Range can be easily drilled for mounting without losing its humidity protection. Thanks to their very robust and attractive IP65 rated POM Housing they can be used for many different applications.

Applications

• Access Control
• Production Control
• Library

Applications

• Industrial Automation
• Asset Tracking
• Access Control
• Waste Management

The BLUEBOX Controller LF-1CH is a 125 kHz read/write device with 1 antenna port for the connection of 1 external antenna.

The BLUEBOX LF program offers the choice of different external antennas available for Proximity and Long-Range applications. All BLUEBOX Controllers have robust CE approved IP65 housings and come with full SDK and comprehensive application SW.

Applications

• Industrial
• Production Control
• Access Control

The BLUEBOX Controller LF-2CH is a 125 kHz read/write device with 2 antenna portsfor the connection of 2 external antennas.

The BLUEBOX LF program offers the choice of different external antennas available for Proximity and Long-Range applications. All BLUEBOX Controllers have robust CE approved IP65 housings and come with full SDK and comprehensive application SW.

Applications

• Industrial
• Production Control
• Access Control

iDTRONIC`s BLUEBOX panel antennas LF fit perfectly with iDTRONIC`s BLUEBOX 125 kHz Controllers. The reading distance can be up to 30 cm (depending on tag type).

Applications

• Industrial Applications
• Production Control
• Supply Chain Management

iDTRONIC`s BLUEBOX On-Metal Antenna LF is designed for applications on metal surfaces. This antenna fits perfectly with iDTRONIC’s BLUEBOX 125 kHz Controllers. The reading distance can be up to 7 cm (depending on tag type).

Applications

• Industrial Applications
• Production Control
• Supply Chain Management

iDTRONIC`s BLUEBOX cylindrical antennas LF are designed for industrial applications. These antennas fit perfectly with iDTRONIC`s BLUEBOX 125 kHz Controllers. The reading distance can be up to 13 cm (depending on tag type).

Applications

• Industrial Applications
• Production Control

iDTRONIC`s BLUEBOX cylindrical Reader LF is the perfect device for industrial applications. This reader with integrated antenna fits into applications where small dimensions are needed. It is compliant to 125 kHz Read Only and Read /Write tags. The reading distance can be up to 10 cm (depending on tag type).

Applications

• Industrial Applications
• Production Control

The BLUEBOX Controller LF Long-Range 1CH is a 125 kHz read/write device with 1 antenna port for the connection of 1 external antenna.

The BLUEBOX LF program offers the choice of different external antennas available for Proximity and Long-Range applications. All BLUEBOX Controllers have robust CE approved IP65 housings and come with full SDK and comprehensive application SW.

Applications

• Industrial
• Production Control
• Access Control

They can be personalized from the customer with RFID enabled label printers or can be ordered pre-personalized from iDTRONIC, for example with barcode.They are available in different sizes. The delivery form is single die cuts on reel.

Applications

• Supply chain
• Warehouse / Logistics
• Document identification
• Book identification

The iDTRONIC Flag Tag UHF fits perfectly for manufacturing and logistics. It is less expensive than hard tags but achieve high read ranges when applied to metal and other substrates.

The iDTRONIC Flag Tag UHF can be adapted to suit your application. The combination of RFID with a barcode, plain text and logos and integration of further security features possible.

Applications

• Identification of metallic goods and parts during production, e.g. Automotive components, steel slabs
• Identification in logistics and retail, e.g. Goods or cases on pallets, pallets, racks, containers

Order no.: SL-FT-UHF –G2XM

The use of returnable transport items (RTI) is an increasing movement in the modern supply chain business, with companies constantly seeking to increase handling efficiencies and transparency, reduce costs and improve environmental. The iDTRONIC RTI Label UHF allows to address these needs with a permanent and economic solution.

The iDTRONIC RTI Label UHF can be adapted to suit your application with additional printing of barcode, plain text or logos.

Applications

• Any plastic item made of PP, PE, HD-PE, PS, ABS, PMMA, PVC, PET, HIPS
• Returnable transport items used in supply chain & logistics e.g. returnable plastic containers (RPC), pallets, roll cages, ingredient bins, dollies, intermediate bulk containers (IBC), crates or trays
• Cases and carriers used in production and automation, e.g. small load carriers (VDA, Galia) or bulk cargo containers

Order Code: SL-WSL-UHF-G2XM

Embed-in-metal technology is the most reliable solution to pre-vent tampering as there is no way to remove the RFID tag with-out destroying the product. iDTRONIC In-Metal Tags UHF enable embedding RFID during the production process of the metal part, reducing application costs and allowing manufacturers and end-users the opportunity to differentiate and deliver greater value.

The option of flush mounting a RFID tag inside metallic assets without having to worry about the impact to read-sensitivity and performance opens the door to new and completely automated inventory tracking for metallic items.

Embedding the iDTRONIC In-Metal Tags UHF ensures durability and eliminates environmental concerns like rain, snow and sun that often keep other tags from functioning. iDTRONIC in-Metal Tags UHF are constructed with robust materials and rated IP68 for high reliability and durability in all types of environments.

They integrate the latest IC technology to deliver the industry’s best performance and memory size while conforming to ISO18000-6C including EPC Class 1 Gen 2.

General Features

• Can be embedded in metallic assets
• Reliable in the harshest environments
• Eliminates shock and sheer impact issues
• Guaranteed secure attachment

Key Features and Benefits

• In-Metal tags with read range of up to 4 meters
• Ceramic Material to handle embeddable in In-Metal applications
• High application temperatures up to +150 °C
• Large user memory (up to 32 kBytes)
• Available dimensions:
      » IM2: 12 × 7 × 3 mm
      » IM3: 25 × 9 × 3 mm
      » IM4: 30 × 30 × 3 mm

iDTRONIC On-Metal UHF tags provide an unrivalled performance-to-size ratio, reducing tag size and allowing customers to attach to small metallic assets.

iDTRONIC On-Metal Tags UHF are constructed with robust materials and rated IP68 for high reliability and durability in all types of environments. They integrate the latest IC technology to deliver the industry’s best performance and memory size while conforming to EPC Class 1 Gen 2 specifications.

Applications

• Tool tracking
• Weapon tracking
• Medical device management
• WIP conveying equipment
• IT management
• Bulk container tracking
• AGV/small vehicle management
• Post-paint oven baking

iDTRONIC’s Mobile RFID Terminal  “UHF Gun“ has been designed to provide Long Range Reading for UHF ISO18000-6 B/C tags and labels. It has an outstanding reading performance with reading distances of up to 2 meters. Thanks to the integrated pistol grip with 4400 mAh battery, the “UHF Gun“ guarantees easy handling and a very high autonomy. Also convenient docking stations make charging and synchronizing easier than ever in both office and vehicle.

The ease of use and portability of the “UHF Gun” combine to deliver exceptional ergonomics, ensuring reliable performance wherever and whenever you need it. The compact size and low weight makes it comfortable to use throughout a full-shift. A 3.5” transflective sunlight readable LCD with LED backlight touch screen provides exceptional clarity and contrast and allows easy reading in a variety of lighting conditions.

The new RFID Terminal “UHF Gun”, the next generation of portable RFID readers from iDTRONIC, delivers maximum performance and reliability in a lightweight and extremely rugged design. It exceeds military specifications for resistance to drops, dust, vibration and both high and low temperatures. Rated at IP54, the mobile handheld is protected against dirt and water sprayed from all directions and can even withstand multiple 1.5 m drops to polished concrete. These features give users the ability to work in nearly any environment and dramatically reduces repair and downtime costs.

The innovative RFID mobile device “UHF Gun” can support intensive working programs, thanks to the integrated 3000 mAh + 4400 mAh high power battery packs. The standard communication is provided with the integrated USB, Bluetooth and WiFi interfaces. Thanks to GSM, GPRS, EDGE options, the communication capability of the “UHF Gun” can be extended further.

The “UHF Gun” offers a wide range of options and accessories such as 1D Laser scanner, 2D Barcode imager, 1,3 Megapixel fixed focus camera with flash, GPS Receiver, Powered Cradle for Vehicle mount applications and single or 4 slot cradle. It runs under Windows CE 5.0 & Windows Mobile 6.0 operating systems It is easily upgradeable and gives unmatched performance, maximizing your software development investment. It is available with the high-performance PXA270 520 MHz, PXA320 820 MHz CPU, 128 MB SD RAM and 256 MB Flash.

The iDTRONIC High-Temp Tag UHF is constructed with robust materials and rated IP68 for high reliability and durability in all types of environments. The tag survives applications with temperatures of up to 250 °C and other harsh elements such as high impact and caustic chemicals.

The design of the iDTRONIC High Temp Tag UHF has been done as well for the use on metal objects/structures. It is possible to achieve reading distances of up to 8 m.

The iDTRONIC High-Temp Tag UHF integrates the latest IC technology to deliver the industry’s best performance and memory size while conforming to EPC Class 1 Gen 2 specifications.

Applications

• Industrial
• Automotive
• High-Temp. Applications

General features

• High performance High-Temp. tag
• High performance On-Metal tag
• IP68 rating for harsh environments
• Passive UHF ISO18000-6C EPC Class 1 Gen 2

Key Features and Benefits

• On-metal tags with read range of up to 6 meters
• IP68 rated rated to handle high application temperatures
• +250 °C application temperature for up to 4 hours
• High user memory (up to 32 kBytes)
• Small form factor with 51 × 37 × 8 mm

Order Code: ST-HTT- UHF-G2XM
