UHF RFID Reader with integrated Antenna
BLUEBOX CX MR IA
– Standard ISO 18000-63
– 15 W @ 27 dBm
– RS232 | RS485, Ethernet, Wiegand or CANbus
– Power Supply via Ethernet (RJ45) or M12
 |
RFID UHF: 840 – 960 MHz | |
 |
Supports Standard ISO 18000-63 (EPC Class 1 Generation 2) | |
 |
Integrated Antenna | |
 |
USB 2.0 Interface | |
 |
RS232 | RS485, Ethernet, Wiegand or CANbus (SAE J1939 or CANopen) | |
 |
IP67 Protection Class | |
 |
Power Supply via Ethernet (RJ45) or M12 | |
|
Optional: Real-Time-Clock (RTC) | |
|
Software Development Kit with expandable Firmware | |
|
Supports ETSI and FCC Regions |
| MECHANICAL SPECIFICATIONS | ||||||
| Housing Material: | Die-cast aluminium, plastic | |||||
| Dimensions: | 110 × 140 × 62 mm | |||||
| Protection Class: | IP67 | |||||
| ELECTRICAL SPECIFICATIONS | ||||||
| Power Supply: | 10 … 36 Vdc, PoE (RJ45 Version) | |||||
| Power Rating: |
15 W @ +27 dBm
|
|||||
| Operating Frequencies: |
840 – 960 MHz, software programmable
|
|||||
| Max. Power: |
max 0.5 W (27 dBm), software programmable in 1 dB steps
|
|||||
| Operating Distance: |
up to 3 meters
|
|||||
| Antenna: | integrated | |||||
| Digital Inputs: |
2 optoisolated inputs, 10 – 36 Vdc, max 20 mA @ 24 Vdc
|
|||||
| Digital Outputs: |
2 relay outputs, 1 A @30 Vdc, 0.5 A @ 125 Vac
|
|||||
| Status: |
3 LED, Buzzer
|
|||||
| Interfaces: |
RS232 / RS485, Ethernet 10 – 100 M, CANbus (SAE J1939 or CANopen)
|
|||||
| Service Interface: |
USB VirtualCom Port (VCP)
|
|||||
| Connections: | M12, Amphenol RJ45 (Ethernet) | |||||
| ENVIRONMENTAL CONDITIONS | ||||||
| Operating Temperature: | -20 °C to +55 °C | |||||
| Storage Temperature: | -40 °C to +85 °C | |||||
| Humidity: |
up to 95 %, non condensing
|
|||||
| APPLICABLE STANDARDS | ||||||
| EMC: | EN 301 489-3 | |||||
| Radio Regulation: | EN 302 208-2 | |||||
| Safety: | CEI EN 60950-1, CEI EN 50364 | |||||
| SUPPORTED STANDARDS | TAGS | ||||||
| Standard ISO 18000-63 (EPC Class 1 Generation 2) | ||||||
| SDK INFORMATION | ||||||
| Supported OS: | Windows XP, Vista, 7, 8 | |||||
| Supported Languages: | C#, C++, serial command protocol | |||||
The BLUEBOX CX MR IA is an industrial read and write device for the latest industry 4.0 and IoT applications in automation and logistics processes. Its RFID UHF controller and integrated antenna operates in global frequency areas from 840 – 960 MHz.
Thanks to its IP67 protection class, the BLUEBOX reader is resistant to rough and demanding environments in the industrial sector.
Data capturing and collection made easy with the various integrated industrial interface options. Real-Time transfer of ongoing processes can be done via the CANbus port. The RS232/485 interface option is especially developed for the direct control of machines. Wiegand is an port for the identification of access control data.
The integration to all common machines or devices is possible with the BLUEBOX CX MR IA RFID reader. The optionally available M12 or RJ45 (Ethernet) connector are suitable for latest industry 4.0 standards.
Through these communication channels, it is also possible to configure the functional parameters and to upgrade the firmware. We offer a software development kit especially for our BLUEBOX series. The ‘BLUEBOX Show’ software of the SDK is foreseen to explicate these operations. Additionally we show the functions of the demo software in our demo software introduction on YouTube.
► Product Presentation
► Demo Software Introduction
► Application Areas
 |
Industrial Automation | |
 |
Asset Tracking | |
 |
Supply Chain | |
 |
Waste Management | |
 |
Access Control |
