ELECTRICAL SPECIFICATIONS | |
|---|---|
| Power Supply | 7.6 … 13.8 Vdc (battery powered) |
| Power Consumption | < 120 mA, standby current < 1 mA (low power mode) |
| Operating Frequency | HF | NFC: 13.56 MHz* |
| Antenna | Integrated* |
| Standard UID output | ISO 14443A UID LSB |
| Antenna | integrated |
| Reader IC | CL 663 |
| RF TX Speed | up to 848 kBd |
| Interfaces | CANbus (SAE J1939 or CANopen) with custom-specific communication protocol |
| Baudrate CANbus | 250 or 500 kbit/s |
| Connectors | JST 04T-JWPF-VSLE-S, 0.33 mm²/ AWG22 wire gauge |
MECHANICAL SPECIFICATIONS | |
| Dimensions | 81.4 × 68.6 × 24.1 mm |
| Weight | 90 g (incl. cable) |
| Material | ABS (Acrylonitrile Butadiene Styrene) |
ENVIRONMENTAL CONDITIONS | |
| Operating Temperature | -10 °C to +50 °C |
| Storage Temperature | -20 °C to +60 °C |
| Humidity | up to 95 %, non condensing |
| MTBF | 200‘000 h |
| IP Protection Class | IP64 (potted electronics) |
SUPPORTED STANDARDS | TAGS | |
| ISO14443A and compatible | Read/write: MIFARE® DESFire®EV1 2K / 4K / 8K, Read UID only: all other ISO14443A RFID tags |
| ISO14443 B and compatible | SRI4K, SRIX4K, AT88RF020, 66CL160S, SR176 |
| ISO15693 and compatible | EM4135, EM4043, EM4x33, EM4x35, I-Code SLI / SLIX, M24LR16/64, TI Tag-it HF-I, SRF55Vxx (my-d vicinity) |
| ISO 18092:2013 | NFC-IP1, NFC-IP2 |
APPLICABLE STANDARDS | |
| EMC | EN 301489-1:2012-04 (v1.9.21) EN 301489-3:2013-12 (V1.6.1) |
| Radio Regulation | EN 300330-1:2015-08 (V1.8.1) EN 300330-2:2015-08 (V1.6.1) |
| Safety | EN 60950-1:2014-08 EN 62369-1:2010-03 EN 50364:2010-11 |
| RoHS 2 | EC Guideline 2011/65/EU and amendment 2015/863/EU, updated by 2017/2102/EU EN 50581:2012 (valid till 2024-07-07) EN 63000:2018 |
| REACH | EU Guideline 1907/2006, updated by 2020/171/EU |
| Certificates | FCC, CE |
SDK INFORMATION | |
| Supported OS | Windows 7, 8, 8.1, 10 |
| Supported Languages | C++, Binary command protocol |
| Demo Software | Windows |
*Reading distance depends on tag, antenna and environmental conditions.
Manage the access control of your vehicle or vehicle fleet by authorizing drivers to operate designated vehicles via NFC/HF transponder. No more time-consuming key boxes or costly key replacements!
The IGNITE-SMART Reader is a battery-powered smart RFID reader which can work as a lock for E-Mobility vehicles, such as electric scooters, electric cars or e-bikes. Its integrated HF and NFC reader supports DESFire and NFC tags and transponders. During production you can program DESFire tags to become RFID keys.
In standard mode, the reader automatically detects a valid RFID key, wakes up the ECU and sends the key number to the ECU. The key number is password-protected and encrypted in the DESFire file system. The reader connects seamlessly with your vehicle using the standardized CANbus (SAE J1939 or CANopen) interface.
The IGNITE-SMART Reader was developed for demanding outdoor usage with its integrated IP64 protection class. It also withstands temperature fluctuations from -10 °C to +50 °C.
The IGNITE-SMART Reader is certified according to RoHS 2 and REACH. It is supplied with a software development kit for Windows systems. This supports the programming languages: Binary command protocol, VS2005 C++ Library. The SDK simplifies the integration into your existing systems.
Application areas
- Electric Mopeds / Scooters
- Electric Cars & Trucks
- E-Bikes
- Golf Carts, Go-Karts, Quads
- Any conventional vehicle with CANbus
ELECTRICAL SPECIFICATIONS | |
|---|---|
| Power Supply | 7.6 … 13.8 Vdc (battery powered) |
| Power Consumption | < 120 mA, standby current < 1 mA (low power mode) |
| Operating Frequency | HF | NFC: 13.56 MHz* |
| Antenna | Integrated* |
| Standard UID output | ISO 14443A UID LSB |
| Antenna | integrated |
| Reader IC | CL 663 |
| RF TX Speed | up to 848 kBd |
| Interfaces | CANbus (SAE J1939 or CANopen) with custom-specific communication protocol |
| Baudrate CANbus | 250 or 500 kbit/s |
| Connectors | JST 04T-JWPF-VSLE-S, 0.33 mm²/ AWG22 wire gauge |
MECHANICAL SPECIFICATIONS | |
| Dimensions | 81.4 × 68.6 × 24.1 mm |
| Weight | 90 g (incl. cable) |
| Material | ABS (Acrylonitrile Butadiene Styrene) |
ENVIRONMENTAL CONDITIONS | |
| Operating Temperature | -10 °C to +50 °C |
| Storage Temperature | -20 °C to +60 °C |
| Humidity | up to 95 %, non condensing |
| MTBF | 200‘000 h |
| IP Protection Class | IP64 (potted electronics) |
SUPPORTED STANDARDS | TAGS | |
| ISO14443A and compatible | Read/write: MIFARE® DESFire®EV1 2K / 4K / 8K, Read UID only: all other ISO14443A RFID tags |
| ISO14443 B and compatible | SRI4K, SRIX4K, AT88RF020, 66CL160S, SR176 |
| ISO15693 and compatible | EM4135, EM4043, EM4x33, EM4x35, I-Code SLI / SLIX, M24LR16/64, TI Tag-it HF-I, SRF55Vxx (my-d vicinity) |
| ISO 18092:2013 | NFC-IP1, NFC-IP2 |
APPLICABLE STANDARDS | |
| EMC | EN 301489-1:2012-04 (v1.9.21) EN 301489-3:2013-12 (V1.6.1) |
| Radio Regulation | EN 300330-1:2015-08 (V1.8.1) EN 300330-2:2015-08 (V1.6.1) |
| Safety | EN 60950-1:2014-08 EN 62369-1:2010-03 EN 50364:2010-11 |
| RoHS 2 | EC Guideline 2011/65/EU and amendment 2015/863/EU, updated by 2017/2102/EU EN 50581:2012 (valid till 2024-07-07) EN 63000:2018 |
| REACH | EU Guideline 1907/2006, updated by 2020/171/EU |
| Certificates | FCC, CE |
SDK INFORMATION | |
| Supported OS | Windows 7, 8, 8.1, 10 |
| Supported Languages | C++, Binary command protocol |
| Demo Software | Windows |
*Reading distance depends on tag, antenna and environmental conditions.
Manage the access control of your vehicle or vehicle fleet by authorizing drivers to operate designated vehicles via NFC/HF transponder. No more time-consuming key boxes or costly key replacements!
The IGNITE-SMART Reader is a battery-powered smart RFID reader which can work as a lock for E-Mobility vehicles, such as electric scooters, electric cars or e-bikes. Its integrated HF and NFC reader supports DESFire and NFC tags and transponders. During production you can program DESFire tags to become RFID keys.
In standard mode, the reader automatically detects a valid RFID key, wakes up the ECU and sends the key number to the ECU. The key number is password-protected and encrypted in the DESFire file system. The reader connects seamlessly with your vehicle using the standardized CANbus (SAE J1939 or CANopen) interface.
The IGNITE-SMART Reader was developed for demanding outdoor usage with its integrated IP64 protection class. It also withstands temperature fluctuations from -10 °C to +50 °C.
The IGNITE-SMART Reader is certified according to RoHS 2 and REACH. It is supplied with a software development kit for Windows systems. This supports the programming languages: Binary command protocol, VS2005 C++ Library. The SDK simplifies the integration into your existing systems.
>Application areas
- Electric Mopeds / Scooters
- Electric Cars & Trucks
- E-Bikes
- Golf Carts, Go-Karts, Quads
- Any conventional vehicle with CANbus
