Rugged Industrial Handheld
C13
Highlights
NFC (ISO 14443 A/B, ISO 15693, ISO 18092)
WiFi | Bluetooth | 3G/4G | GNSS
Front 5.0 MP | Rear 13.0 MP camera
IP65 certified, MIL-STD-810H certified
1.2m Drop - Proof
Specifications
Electrical specifications | |
---|---|
Battery | 3.87 V, 4000 mAh Lithium-ion Battery (removable) |
Memory | 4 GB RAM 64 GB ROM |
Input/Output | Micro USB 2.0 x 1 SIM Card x 1 TF Card x 1 POGO PIN x 1 Φ3.5mm standard earphone jack x 1 |
CPU | ARM, OCTA Core |
Camera | Front: 5.0 Megapixel Rear Main: Camera 13.0MP, Autofocus, |
Display | 5 Inch |
Touch Panel | 5 point G+FF capacitive touch screen Corning® Gorilla® Glass |
Mechanical conditions | |
Dimensions | 157.4 x 74.6 x 24.2mm |
Drop Height | Withstands drops from 1.2 meters onto composite Drop Height wood flooring, while powered on. |
Device Color | Black |
Environmental conditions | |
Operating Temperature | -10 °C up to 55 °C |
Storage Temperature | -20 °C up to 60 °C |
Humidity | 95% (non-condensing) |
Protection Class | IP65 certified, MIL-STD-810H certified |
Communication specifications | |
WiFi | WiFi 802.11 a/b/g/n/ac (2.4G+5G) |
Bluetooth | BT5.0 Transmission distance: 10m |
3G/4G | GSM B2/B3/B5/B8 WCDMA B1/B2/B5/B8 TDS B34/B39 FDD B1/B2/B3/B4/B5/B7/B8/B13/B17/ B20/28AB TDD B38/B39/B40/B41 |
GNSS | Support GPS, Glonass, Beidou (G+G+B) |
Supported standards | Tags | |
NFC 13.56 MHz | |
ISO 14443 A and compatible | Read/write: MIFARE® Classic/1K/4K, MIFARE Ultralight®/C, MIFARE® DESFire®EV1/3, MIFARE® Smart MX, MIFARE® Plus S / X, MIFARE® Pro X, NTAG 213, 215, 216, 196, DNA Read UID only: all other ISO14443A RFID tags |
ISO 14443 B and compatible | SRI4K, SRIX4K, AT88RF020, 66CL160S, SR176 |
ISO 15693 and compatible | EM4135, EM4043, EM4x33, EM4x35, I-Code SLI / SLIX, I-Code SLI-2, M24LR16/64, TI Tag-it HF-I, SRF55Vxx (my-d vicinity) |
ISO 18092 | I-Code ILT-M |
Description
The C13 is a compact rugged handheld computer designed for demanding use in warehouse logistics, field service, express delivery, or mobile payment. Its 5-inch display, 720 × 1280 resolution, and IP65/MIL-STD-810H certification make it ideal for tough working environments.
Powered by an octa-core processor, 4 GB RAM and 64 GB ROM, it runs smoothly on Android™ 11.
It features a 13 MP rear and 5 MP front camera, WiFi, Bluetooth 5.0, 3G/4G, and GNSS (GPS, Glonass, Beidou). The integrated NFC module supports ISO 14443 A/B, ISO 15693, and ISO 18092. Optional accessories like scan triggers, docking stations or vehicle mounts add flexibility
Application areas
- Warehouse logistics
- field service
- Express delivery
