HF | NFC Stick Reader – EVO
Specifications
| Electrical Specifications | |
|---|---|
| Power Supply | USB VCP + HID |
| Power Consumption | <200 mA |
| Operating Frequency | HF | NFC | LEGIC: 13.56 MHz |
| Antenna | integrated |
| Interfaces | USB 2.0 (Plug-and-play) |
| HID Output Format | ISO 14443 A: hexadecimal, lowercase, byte-reverse, LSB ISO 15693: hexadecimal, lowercase, MSB The HID output format can be modified on request. |
| Connector | USB Type A plug |
| Signals | LED shows successful tag communication with colour change. |
| Mechanical Specifications | |
| Dimensions | 75 × 20 × 10 mm |
| Material | ABS (Acrylonitrile butadiene styrene) |
| Protection Class | IP40 |
| Housing Colour | White |
| Weight | 15 g |
| Environmental Conditions | |
| Operating Temperature | -20 °C to +70 °C |
| Storage Temperature | -20 °C to +80 °C |
| Humidity | up to 95 % non-condensing |
| Supported Standards / Tags | |
| ISO 14443 A and compatible | Read/write: MIFARE® Classic/1K/4K, |
| ISO 14443 B and compatible | SRI4K, SRIX4K, AT88RF020, 66CL160S, SR176 |
| ISO 15693 and compatible | M4135, EM4043, EM4x33, EM4x35, I Code SLI / SLIX, M24LR16/64, TI Tag-it HF-I, SRF55Vxx (my-d vicinity) |
| ISO 18000-3M3 and compatible | I-Code ILT-M |
| Applicable Standards | |
| EMC | EN 301489-1:2019-11 (v2.2.3) EN 301489-3:2019-03 (V2.1.1) |
| Radio Regulation | EN 300330-1:2015-03 (V1.8.1) EN 300330-2:2015-03 (V1.6.1) |
| Safety | EC 62368-1:2018-10 (V3.0, valid as of 2020-12-20) |
| RoHS 2 | EC Guideline 2011/65/EU and amendment 2015/863/EU, updated by 2017/2102/EU EN 50581:2012 (valid till 2024-07-07) EN 63000:2018 |
| REACH | EU Guideline 1907/2006, updated by 2020/171/EU |
| Certificates | FCC, CE |
| SDK Information | |
Supported OS | Windows XP, Vista, 7, 8, 8.1, 10 |
| Supported Languages | Binary command protocol, VS2005 C++ |
| Demo Software | Windows |
Description
RFID HF | NFC Stick Reader – EVO with HID + VCP for IoT Applications
The RFID HF | NFC Stick Reader – EVO is a modern and slight plug-and-play RFID read and write device with integrated HID and VCP mode and USB 2.0 interface. It is the perfect RFID reader for latest IoT applications in companies and suitable for a wide variety of applications in ecommerce, telecom, postal, banking or health care.
Adjustable Data Output with HID + VCP
This new versatile RFID reader supports two modes of operation via USB: a virtual comport (VCP) or a Human Interface Device (HID). The VCP mode has a complete read and write access. It is designed for IoT applications and can be easily integrated into any operating system. The HID mode is a keyboard emulation mode. Beside different UID (Serial Numbers) formats, the reader can be set to read out different parts of the user memory as well. The HID mode is perfectly suited for web applications in heterogeneous IT cloud environments.
Supported RFID Transponders and RFID Tags
RFID HF | NFC Stick Reader – EVO supports ISO Standard ISO/IEC 14443A/B, ISO 15693 and ISO 18000-3M3. It reads transponder and tags with MIFARE® Classic, MIFARE® DESFire, NTAG, EMxxxx and I-Code ILT-M chip.
Supported Programming Environment and Languages
The RFID HF | NFC Stick Reader – EVO is certified according to RoHS 2 and REACH. It is supplied with a software development kit for Windows systems. This supports the programming languages: Binary command protocol, VS2005 C++ Library. With the help of our demo software introduction, the SDK simplifies the connection to your existing systems.
Application areas
- E-Ticketing
- Membership Cards
- Access Control
- PC Log On
- NFC & Mobile Applications
- Healthcare Areas
