Rugged Industrial Handheld
C14

Highlights

NFC (ISO 14443 A/B, ISO 15693, ISO 18092)
WiFi | Bluetooth | 4G | GNSS
2D Barcode Scanner
Front 32.0 MP | Rear 48.0 MP camera
IP68 certified, MIL-STD-810H certified
1.5m Drop - Proof

Specifications



Electrical specifications
BatteryBuilt-in Polymer Lithium-ion Battery
3.87 V, 20000 mAh
Memory8 GB RAM | LPDDR4X
256 GB RoM | UFS2.2
ESD±12 kv air discharge,
±8 kv direct discharge
Power Adapter33W Fast Charge Adapter
Type-C CableType-C Data Cable(1m)
Input/OutputType C *1 (Charging/Data/Earphone/Reverse charging 10W)
TF card *1 (MAX 2TB), SIM card *2,
2 of 3 card slot:
Micro Sim+TF or Micro Sim+Nano Sim
CPUARM, Octa-core
CameraFront: 32 Megapixel
Rear Main:
Camera 48MP, Autofocus, Supports PDAF
Rear Secondary Camera1: 20MP Night
Vision, Auto Focus
Rear Secondary Camera2: 2MP Macro
Display6.78 Inch
TFT 20:9
720×1612
520 nits
120Hz
Touch Panel10-point capacitive screen,Hardness above
7H, Scratchresistant,
supports wet hands and gloves operation
Data CollectionFingerprint, Power On/Off & Fingerprint
2-in-1
SensorsLight Sensor
Proximity Sensor
3D Accelerometer
Geomagnetic Sensor
Gyroscope
Gravity Sensor
Barometer
AudioSpeaker *1 4Ω/3W
Earphone *1
Dual-MIC
Motor *1
Audio SMART PA
Other FunctionsCamping Light, Maximum brightness up to 1000 nits,
Breathing Light,
RGB LED strip with a fixed flash frequency,
Infrared Remote Control,
Remote control distance over 10m,
Supports POC (Public Operator Communication) Network Intercom
Mechanical conditions
Dimensions181.1 × 87.8 × 29.05 mm
MaterialABS+PC
Drop HeightWithstands drops from 1.22 meters onto composite
Drop Height wood flooring,
while powered on.
Device ColorBlack+Orange
Environmental conditions
Operating Temperature−20 °C up to +60 °C
Storage Temperature−30 °C up to +70 °C
Humidity95% (non-condensing)
Protection ClassIP68 certified, MIL-STD-810H certified
Communication specifications
WLANWLAN 802.11(a/b/g/n/ac) Frequency
2.4G+5.0G
Dual-band WIFI, Supports AP seamless roaming
5GGSM:
GSM: B2/3/5/8
CDMA: BC0/BC1/BC10
WCDMA: B1/2/4/5/6/8/19
TDD: B34/38/39/40/41

FDD:
B1/2/3/4/5/7/8/12/13/17/18/19/20/25/26/2
8AB/66/71
NR SA: N1/3/5/8/20/28/38/41/71/77/78/79

GNSSSupports GPS/Beidou/Galileo/GLONASS/
QZSS/AGPS
2D Barcode Imager
Barcode Type1D:
UPC / EAN,
Code128,
Code 39,
Code11,
Codabar,
Code 2/5 interleaved,
MSI,

2D:
QR Code,
PDF417,
Micro QR Code,
Aztec Code,
MaxiCode
Supported standards | Tags
NFC 13.56 MHz
ISO 14443 A and compatibleRead/write:
MIFARE® Classic/1K/4K,
MIFARE Ultralight®/C,
MIFARE® DESFire®EV1/3,
MIFARE® Smart MX,
MIFARE® Plus S / X,
MIFARE® Pro X,
NTAG 213, 215, 216, 196, DNA

Read UID only:
all other ISO14443A RFID tags
ISO 14443 B and compatibleSRI4K,
SRIX4K,
AT88RF020,
66CL160S,
SR176
ISO 15693 and compatibleEM4135,
EM4043,
EM4x33,
EM4x35,
I-Code SLI / SLIX,
I-Code SLI-2,
M24LR16/64,
TI Tag-it HF-I,
SRF55Vxx (my-d vicinity)
ISO 18092I-Code ILT-M

Description

The C14 is a high-performance robuster handheld computer built for industrial environments such as logistics, maintenance, and access control. Its 6.78-inch touch display (720 × 1612, 120 Hz), IP68 rating, and MIL-STD-810H certification ensure durability under extreme conditions. Running on Android™ 14 with an octa-core processor, 8 GB RAM, and 256 GB ROM, it delivers strong and reliable performance. The 20,000 mAh battery with 33 W fast charging supports long operating hours. Equipped with four cameras (48 MP main, 20 MP night vision, 2 MP macro, and 32 MP front), a 2D barcode scanner, multiple sensors, NFC and GNSS – the C14 is ready for any mobile task. WiFi, Bluetooth 5.0, and 4G provide robust connectivity wherever needed.

Application areas

  • Access control
  • logistics
  • Maintenance
