Embedded UHF Interface Boards
Specifications
| General Specifications B100 | |
|---|---|
| Description | Embedded UHF interface Board B100 |
| Dimensions | 35 × 22 × 4.6 mm |
| Weight | 3.6 g |
| General Specifications B200 | |
| Description | Embedded UHF interface Board B200 |
| Dimensions | 35 × 45 × 11.6 mm |
| Weight | 14 g |
| General Specifications B900 | |
| Description | Embedded UHF interface Board B900 |
| Dimensions | 160 × 64 × 19.2 mm |
| Weight | 79.8 g |
| Electrical Specifications B100 | |
| Power Supply | USB Type-C 5V |
| Power Consumption | 0.5W during operation of the single board |
| Communication Interface | USB (9600 – 921600 bps) |
| Connectors | 12-Pin FPC and 15-Pin Ribbon |
| GPIO | – |
| Indicator LEDs | – |
| Electrical Specifications B200 | |
| Power Supply | 9-24V with standard adapter (12V/3A) |
| Power Consumption | 0.5W during operation of the single board |
| Communication Interface | RS232 (9600 – 460800 bps) |
| Connectors | 12-Pin FPC and 15-Pin Ribbon |
| GPIO | 1 input, 1 strong driver output (each pull-up current can reach 250mA) |
| Indicator LEDs | Power indicator (green) |
| Electrical Specifications B900 | |
| Power Supply | 9-24V with standard adapter (12V/3A) POE power supply (compatible with 802.3af or 802.3at standard) |
| Power Consumption | Equipped with SIM7400, standby is 1.76W, operation is 16.2W; Single board is 0.7W during operation.
Adopt 803.at method for power |
| Communication Interface | 10M/100M adaptive Ethernet, RS232 (9600 – 230400 bps), USB (9600 – 921600 bps) |
| Connectors | 12-Pin FPC and 15-Pin Ribbon |
| GPIO | 4 input, 4 strong driver output (each pull-up current can reach 250mA) |
| Indicator LEDs | Power indicator (green), Status indicator (red) |
| Environmental Specifications | |
| Operating Temp. | -25°C to +65°C |
| Storage Temp. | -40°C to +85°C |
| Humidity | 5-95% non-condensing |
| SDK Information | |
| Supported OS | Windows, Linux, Android |
| Supported Languages | C, C#/.NET, Java |
| Demo Software | Windows |
Description
The iDTRONIC EMBEDDED UHF INTERFACE BOARDS are designed for easy RF module testing and assembly of complete machines. The product series adopts an industrial-grade design. A variety of modules, such as M600, M620, M630, M650, M670 and M690, can be directly connected to the board.
Standard communication interfaces such as USB Type-C, RS232 and TCP/IP are provided. These boards are convenient for evaluating the performance of RF modules and can be combined with a shell to make a fixed reader with compact structure, convenient installation, and stable performance, suitable for various industrial applications.
The interface boards also facilitate testing of GPIO operations, reset, power-on control, etc. The M100 is powered by USB, while the M200 and M900 are powered by 9-24V. (POE additionally only for M900 (802.3at/af).
iDTRONIC‘s clients can quickly evaluate the performance of RF modules thanks to these boards, and develop their own products based on open-source information.
Application areas
- RFID UHF Module Testing
- Electronics Development
- Production / Manufacturing
