Tablet C9 – RED
Specifications
| Physical characteristics | |
|---|---|
| Dimensions | 230 × 142 × 18 mm |
| Weight | 600 g |
| Display | Gorilla Glass 3 9H 8.0 in. TFT-LCD (1.280 × 800) touch screen with LED backlight |
| Battery | Rechargeable li-ion Polymer 3.8 V, 8.000 mAh* |
| Expansions | 4 TP keys, 4 function keys | 2 PSAM, 1 SIM, 1 TF |
| Performance characteristics | |
| CPU | Cortex A53 2.0 GHz octa-core |
| RAM | ROM | 4 GB | 64 GB |
| Storage | MicroSD (max. 256 GB expansion) |
| Programming Environment | |
| Operating System | Android™ 10 “Q“ |
| SDK | Online available |
| Language | Javascript |
| Environment | Android Studio or Android Eclipse |
| User environment | |
| Operating Temperature | -20 °C to +50 °C |
| Storage Temperature | -20 °C to +70 °C 10 % – 95 % RH (Non-condensing) |
| Protection Class | IP67 |
| Drop Specifications | 1.2 m drop to concrete across the operating temperature range |
| Camera | |
| Megapixel | Rear: 13.0 Megapixel | Front: 5.0 Megapixel |
| Flash | Autofocus with LED Flash |
| Communication | |
| WLAN | 1500 mAh |
| Standby time | Dual Wi-Fi 2.4 | 5.0 GHz A/B/G/N |
| WWAN | 3G WCDMA B1/2100;B2/1900;B5/850;B8/900; 4G LTE FDD-LTE: B1/2100;B3/1800;B7/2600;B20/800; GSM B5/850;B8/900;B3/1800;B2/1900 |
| WPAN | Bluetooth v4.0 |
| GPS | GPS (accuracy up to 5 m) |
| Supported Standards | Tags | |
| ISO 11784 | ISO 11785 | Read only: EM4100 and EM4200 |
*battery power varies by product, duration and application
Description
The RFID Tablet C9 – RED is the Tablet PC Version among our C9 RFID Handhelds.
The RFID Tablet C9 – RED supports the Standards ISO 11784 and ISO 11785 (Read only: EM4100 and EM4200).
The RFID Tablet C9 – RED is especially suitable for near range applications, covering up to a 10 cm reading range*.
Optionally, the RFID tablet pc is available with a 2D barcode reader.
The high-performance 8.000 mAh Li-Ion battery** withstands a working day without any problems thanks to Android 10’s intelligent battery-consumption function.
The latest Android 10 ”Q“ Version has been adapted to the current IoT requirements. The new operating system focuses on performance, stability and energy efficiency — ensuring longer battery life. This is primarily achieved using artificial intelligence. Android 10 also improves the security of mobile tablets. The background activities of apps will be more limited with the new version. As a rule, applications will now only have access to the camera and microphone if they are running in the foreground.
Excellent Technical Specifications for Your Applications
The RFID Tablet C9 – RED is equipped with the Android 10 version by default. It supports the Mobile Device Management (MDM) System: ”Android for Work“ and all other Enterprise Mobile Management (EMM) Systems. The high-performance Cortex A53 2.0 GHz Octa-Core Processor offers enough performance power for virtually any application. The C9 Tablet RFID Mobile Computer is equipped with an integrated 4 GB Working Memory and 64 GB Storage Capacity. The MicroSD card slot offers enough space for your data and may supports memory cards up to 256 GB.
Top Communication Interfaces for More Efficiency
The RFID Tablet C9 – RED is equipped with 4G LTE and supports the communication interfaces: WLAN, WWAN, WPAN, GPS & Bluetooth. The integrated 13 Megapixel Rear Camera documents work processes in high-resolution format. Video calls can be made in very good quality thanks to the 5 Megapixel Front Camera.
Unbreakable Even in Demanding Environments
Our RFID Tablet C9 – RED is applicable in working temperatures of −20 °C to +50 °C. The robust C9 Tablet RFID Mobile Computer can withstands falls up to a height of 1.2 meters without any problems. The C9 Tablet RFID Mobile Computer is protected against the ingress of dust and water with the integrated IP67 protection class.
* depending on tag, tag orientation and envrionmental conditions
** battery power varies by product, duration and application
Application Areas
- Industry 4.0
- Internet of Things
- Logistics
- Access Control
- Patient Identification
